Circuit Breaker

Product Details :

SACE FORMULA range consists of three frame sizes: A1, A2 and A3 up to 630A.

• Ready to use
  Fixed thresholds on trip units, pre-cabled version of accessories and FORMULA link save time putting FORMULA in service.
• Easy to order and to use
  1,2,3, and 4 poles versions up to 250A, no derating up to 50°C and common range of click-in accessories
• Compact and competitive
  Extremely compact dimensions and coordinated depths mean standardized dimensions and savings in distribution boards design.

Product Details :

Product Details :

A complete range of moulded case circuit-breakers up to 3200 A.

All the circuit-breakers, both three-pole and four-pole, are available in the fixed version; sizes T4 and T5 in the plug-in version and T4, T5, T6, and T7 also in the withdrawable one.

• High breaking capacity in compact dimensions
  High values of short circuit breaking capacity are guaranteed at different voltage levels, without compromising overall dimensions.

• Flexibility of use
  Thermomagnetic and electronic trip units are available for use in AC/DC or in AC only. It is possible to interchange trip units keeping the same breaking part, so that installation can be upgraded with fewer costs.

• Advanced protection
  A complete range of electronic trip units is suitable for different level of protection, even enhancing selectivity values with Early Fault Detection and Prevention algorithm.

Product Details :

Product Details :

From a traditional circuit breaker to a real Power Manager. SACE Emax 2 embeds more and more functionalities to become the all-in-one solution able to manage the low-voltage distribution systems.

SACE Emax 2 sets a new circuit breaker benchmark for the needs of today and tomorrow, matching all the new grid requirements thanks to its distinctive features.

• Performance

Four sizes available, ensuring high performances in compact dimensions. Triple marking certification (IEC, UL, CCC). Certified for Class 1 active energy measurement in compliance with the IEC61557-12 standard.

• Control


The All-In-One innovation able to manage any conditions of the grid thanks to advanced functions such as Load Shedding, Power Controller, ATS, Interface Protection, Synchrocheck logics, Adaptive Protection.

• Connectivity


Perfect integration into all automation and energy management systems thanks to the eight communication protocols supported. Easy connection to the cloud computing platform ABB AbilityTM Electrical Distribution Control System. Remote connection through the embedded Bluetooth Low Energy technology.

• Ease of use


Easy and safe operations and maintenance. Plug & play accessorizing. User friendly commissioning tools. Platform able to evolve during the lifecycle through the ABB Ability MarketplaceTM offering.

ACB / Air Circuit Breaker

Product Details :

Kurva C
Jumlah Pole: 1 - 4
Icn (IEC 60898): 4,5 kA
Range Arus: 2 - 40 Amperes
Range Tegangan: 220VAC 1 Pole, 440VAC 2-4 Poles

Kami juga menjual berbaga macam MCB / Miniature Circuit Breaker lainnya.

Product Details :

S 800 B-C :

• Kurva C
• Jumlah Pole: 1 - 4
• Icn (IEC 60947-2): 16 kA
• Range Arus: 32 - 125 Amperes
• Range Tegangan: 253VAC, 440VAC (2-4 pole)

S 800 C-C :

• Kurva C
• Jumlah Pole: 1 - 4
• Icn (IEC 60898): 15 kA
• Icn (IEC 60947-2): 25 kA
• Range Arus: 10 - 125 Amperes
• Range Tegangan: 254VAC, 125 VDC (1 pole), 440VAC (2-4 pole), 250VDC (2 pole in series, Icu 10kA), 375 VDC (3 pole in series, Icu 10kA), 500 VDC (4 pole in series, Icu 10kA)

S 800 N-C :

• Kurva C
• Jumlah Pole: 1 - 4
• Icn (IEC 60898): 20 kA
• Icn (IEC 60947-2): 36 kA
• Range Arus: 10 - 125 Amperes
• Range Tegangan: 400VAC, 125 VDC (1 pole), 690VAC (2-4 pole), 250VDC (2 pole in series, Icu 10kA), 375 VDC (3 pole in series, Icu 10kA), 500 VDC (4 pole in series, Icu 10kA)

S 800 S-C :

• Kurva C
• Jumlah Pole: 1 - 4
• Icn (IEC 60898): 25 kA
• Icn (IEC 60947-2): 50 kA
• Range Arus: 10 - 125 Amperes
• Range Tegangan: 400VAC, 125 VDC (1 pole), 690VAC (2-4 pole), 250VDC (2 pole in series, Icu 10kA), 375 VDC (3 pole in series, Icu 10kA), 500 VDC (4 pole in series, Icu 10kA)

MCB / Miniature Circuit Breaker

Product Details :

SH 200 LC :

• Kurva C
• Jumlah Pole: 1 - 4
• Icn (IEC 60898): 4,5 kA
• Range Arus: 2 - 40 Amperes
• Range Tegangan: 220VAC 1 Pole, 440VAC 2-4 Poles

SH 200 C :

• Kurva C
• Jumlah Pole: 1 - 4
• Icn (IEC 60898): 6 kA
• Range Arus: 6 - 40 Amperes
• Range Tegangan: 220VAC 1 Pole, 440VAC 2-4 Poles

S 200 C :

• Kurva C
• Jumlah Pole: 1 - 4
• Icn (IEC 60898): 6 kA
• Icu (IEC 60947-2): 10 kA
• Range Arus: 1 - 63 Amperes
• Range Tegangan: 253VAC, 72 VDC (1 pole), 440VAC (2-4 pole), 125 VDC (2 pole in series)

S 200 K :

• Kurva K
• Jumlah Pole: 1 - 4
• Icn (IEC 60947-2): 10 kA
• Range Arus: 1 - 63 Amperes
• Range Tegangan: 253VAC, 72 VDC (1 pole), 440VAC (2-4 pole), 125 VDC (2 pole in series)

S 200 M-C :

• Kurva C
• Jumlah Pole: 1 - 4
• Icn (IEC 60898): 10 kA
• Icu (IEC 60947-2): 10-15 kA
• Range Arus: 1 - 63 Amperes
• Range Tegangan: 253VAC, 72 VDC (1 pole), 440VAC (2-4 pole), 125 VDC (2 pole in series)

S 200 M-K :

• Kurva K
• Jumlah Pole: 1 - 4
• Icu (IEC 60947-2): 10 kA
• Range Arus: 1 - 63 Amperes
• Range Tegangan: 253VAC, 72 VDC (1 pole), 440VAC (2-4 pole), 125 VDC (2 pole in series)

S 200 P-C :

• Kurva C
• Jumlah Pole: 1 - 4
• Icn (IEC 60898): 25 kA for <= 25A. 15kA for > 25A
• Icn (IEC 60947-2): 25 kA for <= 25A. 15kA for > 25A
• Range Arus: 1 - 63 Amperes
• Range Tegangan: 253VAC, 72 VDC (1 pole), 440VAC (2-4 pole), 125 VDC (2 pole in series)

S 200 P-K :

• Kurva K
• Jumlah Pole: 1 - 4
• Icn (IEC 60947-2): 25 kA for <= 25A. 15kA for > 25A
• Range Arus: 1 - 63 Amperes
• Range Tegangan: 253VAC, 72 VDC (1 pole), 440VAC (2-4 pole), 125 VDC (2 pole in series)

S 200 M UC-C :

• Kurva C
• Jumlah Pole: 1 - 4
• Icu (IEC 60947-2): 10 kA
• Range Arus: 0.5 - 63 Amperes
• Range Tegangan: 254VAC, 220 VDC (1 pole), 440VAC (2-4 pole), 440 VDC (2 pole in series)

Jual Abb Mcb S200 Series

S 200 M UC-K :

• Kurva K
• Jumlah Pole: 1 - 4
• Icu (IEC 60947-2): 10 kA
• Range Arus: 0.5 - 63 Amperes
• Range Tegangan: 254VAC, 220 VDC (1 pole), 440VAC (2-4 pole), 440 VDC (2 pole in series)

MCB / Miniature Circuit Breaker

Product Details :

Jumlah Pole: 3 - 4
Adjustable: 0.4 - 1 In
Electronic trip EKIP DIP LI
Tersedia fixed type dan draw out type
Icu (IEC 60947-2): 50 kA
Range Arus: 630 - 1600 Amperes
Range Tegangan: 415 VAC

ACB / Air Circuit Breaker

Product Details :

ACB / Air Circuit Breaker

Standard                                  IEC 60947-2

Kapasitas pemutusan              (Icu) 50kA pada 380/415 VAC

Tipe unit trip                             Ekip DIP

Proteksi                                    tipe LI

                                                  L = l1 =0,4... 1 x In t1 =3, 12,24,...,144 dtk pd I=3xl1(t=k/l²)

                                                  l= l3 = 1,5. . . 15 x In t3 = instan (t=k)

Jenis Koneksi                           terminal belakang horizontal (HR) ²

Tipe insulasi                             drawout type (D/O) (jenis tarik)

Lengkapan standar                   - termasuk 4 C/O kontak bantu

                                                  -  termasuk indikasi trip mekanik dan listrik

                                                  - termasuk terminal kontak bantu

In   : 630 Ampere

Ref : 1SDA072061
